Sacrificial protection
Zinc Electroplating
As specialist zinc platers, we electroplate steel components with a sacrificial zinc coating to BS EN ISO 2081: the zinc corrodes in preference to the steel beneath, protecting the part long after minor damage. It's a cost-effective, dimensionally accurate finish with a range of passivate colours and topcoats to suit cosmetic and performance needs.
- Thickness
- 5–25 microns
- Standards
- BS EN ISO 2081
- Turnaround
- 5–7 working days
Process data
| Materials | Mild steel, brass, copper, stainless steel |
|---|---|
| Thickness | Typically 5–25 microns |
| Finishes | Clear (blue), colour, black passivate · Enseal 40 & JS500 topcoats |
| Standards | BS EN ISO 2081 |
| Compliance | RoHS, REACH, ELV, and WEEE compliant |
| Turnaround | Typically 5–7 working days |
Passivates & topcoats
A passivate is a thin conversion layer applied over the zinc to boost corrosion resistance and set the colour: clear/blue, black, or coloured. Topcoats such as Enseal 40 and JS500 add further protection and consistency.
Maximum part size
Zinc + colour passivate: max 20 kg
| Finish | Max weight | Max size (L × D × Br) |
|---|---|---|
| Zinc + colour passivate | 20 kg | 800 × 300 × 600 mm |
| Zinc + clear passivate | 20 kg | 800 × 300 × 600 mm |
| Zinc + black passivate | 15 kg | 500 × 200 × 550 mm |
Frequently asked questions
- ISO 9001 certified
- Made in Britain member
- IMF member (Institute of Metal Finishing)
- Free Certificate of Conformity
- Fast turnaround: 3–7 days, 24-hour service on request
- 25+ years’ combined experience
